Specifications:
- Premium Sound from Northern Europe
- Dome tweeter cone effectively decreases distortion.
- Patented design of tweeter phase cone provides precise sound directivity.
- CNC precision basket ensures extremely-low level of distortion.
- The 6-layer composite paper cone is water-proof, humidity-proof and high temperature resistance, which also provides high •resolution and excellent transient response.
- Patented symmetric driving magnet has great control of its eddy current.
- Kapton voice coin, featured by high temperature resistance, ensures low distortion.
- Series Premium 6.5 inch 3-way Speaker Component
- Rated Impedance 4 Ohms
- Rated Power 100W
- Sensibility 90DB
- Frequency Response 46Hz-30000Hz
- Magnet Top level neodymium magnet system
- Tweeter EU-T1II
- 29mm Dome tweeter, patented phase cone, patented symmetric driving magnet
- Midrange EU-MD3II
- 90mm 6-layer composite paper cone, low-loss linear suspension,CNC precision basket, patented symmetric driving magnet
- Midbass EU-MW6II
- 165mm 6-layer composite paper cone, low-loss linear suspension, CNC precision basket, patented symmetric driving magnet
- External Diameter: Tweeter 29mm(1.15inch)/Midrange 90mm(3inch)/ Midbass 165mm(6.5inch)
- EU-T1II EU-MW6II EU-MW611
- Dimension mm 29 90 165
- Loop 1 1 1
- Frequency Response Hz 625-30000 106-8000 46-4000
- Sensibility dB 88 90 90
- Impedance Ohm 4 4 4
- Rated Power W 50 50 70
- Resonant Frequency Hz 625 106 46
- Mechanical Quality Factor QMS 5.73 7.52 7.43
- Electric Quality Factor QES 1.43 0.33 0.29
- General Quality Factor QTS 1.14 0.32 0.28
- Equivalent Volume VAS 0.01L 1L 147.8
