10″ Subwoofer
Steel frame
2″ voice coil
2 x 4 Ohms
1100W

The completely redesigned 200e series offers a truly expansive bass response at an affordable price. This series is designed to be so sensitive that you don’t need high-power amplifiers, but can be played with an amplifier as small as 100-300W.

The 200e series is suitable for both sealed and reflex enclosures

. Enclosure recommendations:

Reflex: 14 – 22L
Sealed: 14 – 20L

Speaker Size (In): 10
Watts RMS: 350
Watts Peak: 1100
Impedance: D4
VCD (In): 2
Fs (Hz): 35
Qms: 11.107
Qes: 0.53
Qts: 0.506
Vas (Liters): 32.495
BL (TM): 20
Xmech (MM): 30
Xmax (MM): 10
Frame OD (In): 10.12
Frame OD w/ Gasket (In): 10.25
Mounting Diameter (In): 9
Mounting Depth (In): 4.75
Motor Diameter (In): 1.7
Motor Depth (In): 5.27
Magnet Weight (Oz): 55
Woofer Displacement (CuFt): 0.05
Sealed Enclosure (CuFt): 0.5 – 0.7
Ported Enclosure (CuFt): 0.5 – 1.25
Shipping Weight (Lbs): 12.5
