Specifications:
Features
Nominal Diameter: 10″ / 254mm
Nominal Impedance Available: 4 ohms, 8 ohms
RMS Power Handling: 700 watts
MAX Power Handling: 1400 watts
Sensitivity (1w/1m): 98dB
Frequency Response: 60Hz-6KHz
Recommended HI Pass Crossover: 80Hz
Sold in Pair or Single: Single
Grill Included: No
Motor
Voice Coil Diameter: 3.5″ / 89mm
Voice Coil Former Material: Kapton
Winding Material: CCAW (2 Layers IN/OUT)
Cone Material: Non-pressed Paper
Dust Cap Material: Paper
Bullet Material: N/A
Bullet Colour/Finish: N/A
Surround Material: Cloth
Basket Material: Aluminium
Basket Colour/Finish: Satin Black
Magnet Material: Ferrite
Magnet Weight: 93 Oz
Displacement Volume: 1.44L / 0.051ft3
Thiele & Small Parameters
Equivalent Volume Vas: 21L / 0.741ft3
Excursion (one way) Xmax: 4mm
Free Air Resonance Fs: 70Hz
Mechanical Factor Qms: 3.796
